No. 265 Automatic Densimeter, DSG-1 ( Density Tester )

/
/
 No. 265 Automatic Densimeter, DSG-1 ( Density Tester )
Loading...

 No. 265 Automatic Densimeter, DSG-1 ( Density Tester )

The Automatic Densimeter measures density of materials such as polymer or rubber in various forms.

The weighing operation is automatic and the density of the sample is automatically calculated and displayed on the screen at the end of the test.

By using the optional attachments, it can also be used to determine density/Specific gravity of liquids and rate of change of volume etc.

An optional temperature sensor can also be added to allow direct measurement and input of air and liquid temperatures.

Add To Enquiry
Loading...

Description

FEATURES

  • The density of a wide range of materials from metals to foam bodies can be measured.
  • Measurement can be performed in a short time (approximately 15 seconds per sample).
  • Very simple operation-only mounting/dismounting the sample and pushing the Start button.
  • In addition to distilled water, other liquids such as ethanol can also be used as the standard immersion liquid depending on sample.
  • Beaker lifting speed & upper/lower stop position is adjustable. Allows you to reduce test cycles.
  • Density tables (2 kinds each for liquid & air) are installed. Allows you to input immersion liquid density & air density by temperature.
  • Automatic input of immersion liquid & air density is available. (Optional)
  • Immersion liquid temperature can be controlled. (Optional)

Specifications

Model DSG-1
Balance unit capacity 100g
Balance unit resolution 0.0001g (0.1mg)
Beaker lifting mechanism Motorized
Immersion time range 1 to 999sec.
Power supply Single-phase, AC100 to 240V, 50/60Hz, 0.1kVA
Dimensions W290×D443×H890mm
Mass (Approx.) 35kg

Related standards

ISO 1183-1 Plastics — Methods for determining the density of non-cellular plastics — Part 1: Immersion method, liquid pycnometer method and titration method
ISO 2781 Rubber, vulcanized or thermoplastic — Determination of density
ASTM D792 Standard Test Methods for Density and Specific Gravity (Relative Density) of Plastics by Displacement
